QSC
QSC GXD8 Professional Power Amplifiers
QSC GXD8 Professional Power Amplifiers
Regular price
Rs. 72,891.00
Regular price
Rs. 124,000.00
Sale price
Rs. 72,891.00
Unit price
per
Tax included.
Couldn't load pickup availability
Features
- High peak output power with up to 1600 watts from the GXD 4 and a whopping 4500 Watts from the GXD 8.
- Power levels matched to the most popular loudspeakers and optimized for maximum real-world headroom into 4Ī© and 8Ī© speaker systems.
- Class D output stage with a universal power supply for high performance and efficiency.
- Extensive and powerful loudspeaker processing built in. Includes high and low-pass filters, 4-band parameteric EQ, limiting, and delay.
- E Series Entertainment System DSP Tunings are now available for GXD processing amplifiers:
Ā Ā Ā Ā Ā Ā Ā - Visit theĀ GXD Firmware UpdaterĀ to download and update
| SPECIFICATIONS | GXD 4 | GXD 8 | ||||
| Ā | Output power per channel | |||||
| 8Ī© dynamic, both channels driven | 600 W | 1500 W | ||||
| 4Ī© dynamic, both channels driven | 800 W | 2250 W | ||||
| 8Ī© continuous, both channels driven | 400 W | 800 W | ||||
| 4Ī© continuous, both channels driven | 600 W | 1200 W | ||||
| Distortion (typical) 1 kHz at full rated power |
< 1% THDĀ | |||||
| Signal to Noise (A weighted, 20 Hzā20 kHz) |
100 dBĀ | |||||
| Input Sensitivity | 1.2 Vrms, 3.9 VrmsĀ | |||||
| Maximum Voltage Gain | 33.5 dB | 36.5 dB | ||||
| Output Circuitry | Class D | |||||
| Power Requirements | 1/8 power at 4Ī© | |||||
| - 100 V AC | 3.4 A | 6.2 A | ||||
| - 120 V AC | 2.9 A | 5.6 A | ||||
| - 230 V AC | 1.6 A | 3.2 A | ||||
| Frequency Response (20 Hzā20 kHz) |
+0.7 dB, -0.8 dB | |||||
| Dynamic Headroom (4Ī©) | 1.25 dB | 2.73 dB | ||||
| Damping Factor (8Ī©) | 100 | |||||
| Input Impedance | 20 kĪ© (balanced), 10 kĪ© (unbalanced) | |||||
| Maximum Input Level | +23.5 dBu | |||||
| Input Connectors (each channel) |
3-pin XLR/F / 1/4-inch TRS, balanced | |||||
| Output Connectors (each channel) |
NL4, binding posts NL4 pinout: ā¢ Ā Channel A on 1+, 1-; Channel B on 2+, 2- ā¢Ā Ā Channel B on 1+, 1- |
|||||
| Amplifier and Load Protection | Short circuit, open circuit, thermal, RF protection Load protected against DC faults |
|||||
| Front Panel Controls and Indicators | 2 Ć Rotary Encoders 3 Ć Operational buttons (HOME, ENTER, EXIT) 2 Ć Green Signal LEDs indicate signal presence 2 Ć Red A/D Clip LEDs indicate input over-drive and/or amplifier current clipping Blue Power LED ring indicates AC on 2.12-inch Ć 1.0-inch, 256 Ć 128 pixel LCD |
|||||
| DSP Functions | High-pass filter, 4th-order Linkwitz-Riley, adjustable frequency 20 Hz to 4 kHz Low-pass filter, 4th-order Linkwitz-Riley, adjustable frequency 60 Hz to 4 kHz 4-band parametric EQ with variable frequency, gain, and bandwidth Peak limiter with power, agressiveness, and impedance selection Delay 50 msec max. |
|||||
| Product Dimensions (HĆWĆD) | 89Ā Ć 483 Ć 259 mm 3.5 (2 RU) Ć 19 Ć 10.2 in |
|||||
| Carton Dimensions (HĆWĆD) | 600 Ć 370 Ć 153 mm 23.6 Ć 14.6 Ć 6 in |
|||||
| Net Weight | 5.1 kg / 11.3 lb | 6 kg / 13.2 lb | ||||
| Shipping Weight | 7 kg / 15.4 lb | 7.9 kg / 17.4 lb | ||||
| Agency Approvals | UL, CE, RoHS/WEEE compliant | |||||
| Carton and Contents | Power cable and quick start guide | |||||
Ā
All specifications are subject to change without notice.
